GTTM 350 | Abrasive Cutting Machine
Features
- Abrasive System: Specialized disc technology for dense profiles and solid materials.
- Drive Unit: High-output motor system maintaining consistent disc speed.
- Swivel Capability: Mechanism for diverse industrial miter cutting applications.
- Vise Group: Reinforced vise assembly for vibration-free clamping.
- Cooling: Integrated circulation pump and tank for soluble oil.
- Maintenance: Integrated air blow gun system.
- Frame: Heavy-duty steel construction for abrasive operations.
Technical Data
| Category | Feature | Value (GTTM 350) |
| Capacity | Blade Diameter | 350 mm |
| 90° Cutting (Round) | 100 mm | |
| 90° Cutting (Sq / Rect) | 100 x 100 / 120 x 90 mm | |
| Cutting Disc | Optional | |
| Motor & Power | Main Motor Power | 5 kW |
| Rotational Speed | 5,400 rpm | |
| Infrastructure | Voltage Supply | 400 V |
| Frequency | 50 / 60 Hz | |
| Control & Drive | Manual / Abrasive Disc | |
| Air Blow Gun | Integrated | |
| Physical Dimensions | Machine Dimensions (WxLxH) | 1,170 x 710 x 1,410 mm |
| Machine Net Weight | 171 kg | |
| Logistics | Shipping Dimensions (WxLxH) | 1,190 x 730 x 1,560 mm |
| Total Gross Weight | 185 kg |
